Broadband Dielectric Mirrors

High efficiency broadband reflectivity
Ultra hard dielectric coatings
Durable, easy to clean
High damage threshold

Features
High reflectance for both S- and P- polarized light
Super polished mirror substrates
Super-smooth polishing
Exceptional environmental durability, reliability
Minimum thermal and absorption effects
In-house OEM and custom manufacturing solutions

Applications
CW and Nanosecond Lasers ... etc.
Please contact us for more specific applications and markets.

MicoSpectra specializes in the design and manufacture custom optics, thin film coatings and optical assemblies for prototype, research and OEM applications.

Optical material	N-BK7, UV Fused Silica, etc.
Size	2mm to 80mm 10mm, 12.7mm, 15mm, 20mm, 25.4mm, 30mm, etc. Round and rectangular custom size available
Surface quality	10-5 Scratch-Dig
Surface flatness	1/10λ
Surface roughness	<2 Å

Wavelength range	266nm – 3000nm
Typical wavelength	350-400nm, 400-750nm, 750-1100nm, 1300-1600nm
Angle of Incidence	0˚ to 45˚
Reflectivity	Ravg > 99% for S- and P- Polarization for AOI from 0 to 45°
Damage Threshold	10 kW/cm
