Thin Film Plate Polarizers

Optimized for higher-power lasers
Extinction Ratio Tp:Ts>10000:1
High Damage Threshold > 10J/cm²

Features
Durability, Reliability
Super-smooth polishing
Minimum absorption and scattering losses
In-house OEM and custom manufacturing solutions

Applications
High Energy Nd:YAG Laser … etc.
Please contact us for more specific applications and markets.

If you are looking for high power PBS, Polarizing Cube Beamsplitters, please contact us for details.

Optical material UV Fused Silica, etc.
Size 2mm to 80mm
10mm, 12.7mm, 15mm, 20mm, 25.4mm, 30mm, etc.
Round and rectangular custom size available
Surface quality 20-10 Scratch-Dig
Surface flatness < 1/4λ @ 632.8nm
Parallelism 30 arc sec
Wavelength 1064nm, 532nm, custom wavelength
Clear Aperture >90% of central dimension
Damage Threshold 10 J/cm2 with 10 nsec pulses
Optional wavelength* UV
266nm, 355nm, 405nm, custom
Laser line
532nm, 633nm, 780nm, 830nm, 980nm, 1064nm, 1310nm, 1550nm, custom
Optional extinction ratio* Tp:Ts>200:1
Tp:Ts>500:1
Tp:Ts>1000:1
Tp:Ts>2000:1
Tp:Ts>5000:1
Tp:Ts>10000:1

*For the optional needs, please contact us for details.
